Electric Pressure Washer Pumps

An electric rig earns its keep in the places a gas machine cannot go. Parking garages, commercial kitchens, food plants, and any job with a noise limit all call for an electric pressure washer pump. Sun Brite Supply carries flange-mount triplex pumps, hollow shaft pumps, axial units with the unloader already installed, and 12 volt soft wash pumps. Tell us your motor's RPM and horsepower at 301-519-9274 and we will pair the right pump to it before you order.

How to Match an Electric Pressure Washer Pump to Your Motor

Gas pump sizing guides skip the two things that actually trip people up on electric builds: motor speed and shaft style. Electric motors come in two common speeds, and a pump built for one will not survive on the other. Here is how to get the match right the first time.

Motor Speed: 3450 RPM or 1725 RPM

Check the motor nameplate before anything else. A 3450 RPM motor needs a pump designed for that speed, like the GP 2SF series. A 1725 RPM motor needs a low-speed pump with larger displacement, like the EZ and FWS series. Bolt a 1725 RPM pump to a 3450 motor and it will cavitate and hammer itself apart. Run a 3450 pump at 1725 and you get half the flow and pressure you paid for. The slower pumps cost more up front because they move more water per revolution, and they last longer for the same reason. Less speed means less heat and less packing wear.

Shaft and Mounting: Solid Flange or Hollow Shaft

Electric pumps mount two ways. Flange-mount pumps slide onto a 5/8" solid motor shaft and bolt to the motor face, which keeps the package short and rigid. Hollow shaft pumps, usually 1 1/8" bore, slip over the motor shaft and clamp in place. The hollow shaft style dominates on 1725 RPM close-coupled builds because it removes the coupler entirely. Measure your motor shaft and check the frame face before ordering. A pump with the wrong bore is a paperweight until you return it.

Sizing the Motor Behind the Pump

Electric motors are rated for continuous duty, so the divisor changes from the gas formula. Use HP = (GPM x PSI) / 1460. A 2 GPM, 2000 PSI pump needs about 2.7 HP at the shaft. A 4 GPM, 3000 PSI pump needs roughly 8 HP, which on single-phase power means serious amp draw. This is why most 120V machines top out near 2 GPM and 2000 PSI. If you want more output than that on electric, plan for a 230V circuit or three-phase power before you buy the pump.

Axial or Triplex on an Electric Build

The AXD series axial pumps come with the unloader and chemical injector already fitted, which makes them the fast, budget way to revive a homeowner-grade electric machine. Expect a few hundred hours of life and treat them as sealed units. Triplex pumps like the 2SF and EZ series cost more, run for thousands of hours, and can be rebuilt with seal and valve kits when they finally wear. For a machine that works every week, the triplex pays for itself the first time you rebuild it instead of replacing it.

Electric Pump Lookup Table

Prices change with vendor costs. Call for current pricing and lead time on any pump listed.

12 Volt Pumps for Soft Wash Rigs

Not every electric pump is a high pressure pump. The Everflo 12 volt diaphragm pumps in this collection run 60 to 70 PSI at 2 to 5.5 GPM off a battery, which is exactly what a soft wash system wants for pushing bleach mix onto siding and roofs. The EFSW5500 is built with hypochlorite-resistant internals, so it handles house wash mix without eating its own valves. Pair one with a low pressure reel and a bandit-style gun and you have a roof rig for under $300 in pump hardware.

From the Field

The failure we see most on electric machines is heat, not wear. An electric washer gets used indoors, the trigger gets released, and the pump sits in bypass while the operator moves a mat or answers a phone. Two minutes of bypass cooks the water in the head past 140 degrees and the packings go soon after. Every electric pump build that leaves our counter gets a thermal relief valve, no exceptions. It is a $20 part that dumps hot water before it kills a $700 pump. Second lesson: milky pump oil on an electric unit almost always means the machine was stored outside and froze. Check the oil window before the season starts, not after the first job.

Related Collections

• All pressure washer pumps including gas-drive models
• Pumps Made Ready with unloader and plumbing installed
• 12 volt pumps for soft wash and sprayer builds
• General Pump and General Pump parts
• Unloader valves and thermal relief valves
• Pump oil and electrical components
• Near Gaithersburg? Get sizing help in person at our Maryland pressure washer store

Frequently Asked Questions

Can I replace the pump on my electric pressure washer?

Usually, yes. Match the motor speed, shaft size, and mounting style and the swap is a wrench job. Homeowner machines with plastic-cased axial pumps are the trickiest, so send us a photo of your motor plate and pump before ordering and we will confirm fit.

What RPM pump does my electric motor need?

Read the motor nameplate. 3450 RPM motors take high-speed pumps like the 2SF series. 1725 and 1750 RPM motors take low-speed pumps like the EZ, BD, and FWS series. The speeds are not interchangeable.

How big a motor do I need for my pump?

Use HP = (GPM x PSI) / 1460 for electric motors. A 2 GPM, 2000 PSI pump wants about 2.7 HP. Anything past 2 GPM at 2000 PSI generally needs 230V or three-phase power to feed the motor.

What is the difference between axial and triplex electric pumps?

Axial pumps are compact, cheaper, and sealed, good for a few hundred hours. Triplex pumps run thousands of hours and rebuild with inexpensive seal and valve kits. Weekly users should buy triplex and rebuild instead of replacing.

Can an electric pump handle hot water?

Only specific models. Standard pumps want feed water under about 140 degrees. The 2SFX30ESV3 in this collection is rated for 190 degree inlet water with stainless valves, which is the right pick for recycled or heated feed water.

What is a hollow shaft pump?

A pump with a bored crankshaft, commonly 1 1/8", that slides directly over the motor shaft and clamps on. It removes couplers and alignment work, which is why most 1750 RPM close-coupled electric builds use one.
